Description
Designer: Fabio Pelizzari
The planter PELIZZARI is made in steel 20/10 thickness. The upper part of the planter is bent on the inside, resulting in an edge of 40 mm strengthening the whole structure. The left side of the planter is 450 mm high, whereas the right side measures 300 mm. On the base of the planter there’s a receding base of 50 mm each side, with H 50 mm. On the bottom of the planter 2 drain pipes, made in tubular steel, section 16X2 mm, H 50 mm, are welded. For the fixing to the ground through specific bolts (not provided) there are 4 holes 10 mm diam.
For the realization of this product made in Italy, Steel EN10111DD11 is used and later treated with a cycle of sandblasting, cataphoresis and powder coating. Such cycle is meant to guarantee the protection of the painted products, in an environment of C4 corrosion class, as requested by the UNI regulations EN ISO 12944-2. The products are eventually polyester-powder coated with RAL colours at choice.
As an alternative to steel EN10111DD11, the production in corten is also available, on demand. In this case the material is treated with a specific oxidation process.
Max dimensions:
Height left: 450 mm
Height right: 300 mm
Width: 400 mm
Length: 1500 mm
Capacity: 205 lt
Weight: 35 kg
Material: steel
